Hp agilent 3776B pcm termial test set opt 001 HP3776B
HP 3776B PCM Terminal Test Set!
This HP 3776B PCM test set appears to be working - it turns on, responds to buttons, etc. It comes with Option 001 - Data Measurements that conform to IEEE STD 743 - 1984. It also has an Agilent 2003 calibration. It runs on either 110-120V or 220-240V AC (selectable with the switch at the back).
The Service Manual is available from Agilent - just follow the link.
Here is some additional information about this item:
* Network test of 4 kHz channels
* VF and 2/1.5 Mb/s interface as standard
* Voice, PCM, and data measurements in one portable instrument
* Framing and signaling bits setting and monitoring
The 3776B PCM Terminal Test Set interfaces directly at the analog and digital level in mixed analog/digital networks. This unit is suitable for North American/Japanese/CCITT networks. Used in installation, commissioning and maintenance, the 3776B ensures optimum performance for each section (e.g., PCM channel bank, digital switching system or transmultiplexer) of the network. The 3776B provides comprehensive voice, PCM and data measurements for testing 4 kHz bandwidth analog and digital channels. It replaces the collection of independent analog and digital test equipment previously used in a mixed system environment with one compact instrument. Features include: Pre-programmed default measurement parameters. User-modified measurement parameters held in non-volatile memory. Measurement sequences can be downloaded from a controller to the 3776B and run independently.
