Emco compact 5 lathe instruction manual
This is a reproduction, not a photocopy, of a Emco Compact 5 Instruction Manual only. This 55 page manual covers everything dealing with the operation of this lathe that you can imagine. Plus, how to install and adjust all of the attachments made for this lathe, including a section on how to use the milling attachment. There is also information on wiring schematics as well.
Accident Prevention.....................................................................3
Technical Data.............................................................................4
Basic Equipment, Care of machine...............................................5
Accessories lathe (summary)........................................................6
Turning tools............................................................................9/l0
Setting up the machine, electrical Connection..............................11
Main Components................................................................12-16
Splashguard...............................................................................16
Turning between centers.............................................................17
Clamping devices for Workpieces..............................................18
3-jaw chuck.........................................................................19-22
Clamping plate...........................................................................22
Independent chuck.....................................................................23
Collet chuck attachment.............................................................24
2-way toolholder, Quick-change toolholder................................25
Travelling steady, Steady rest................................................26/28
Automatic feed mechanism.........................................................28
Mounting the gears................................................................29/30
Thread pitches, gear combinations.........................................30/31
Adjustments...............................................................................32
Lubrication.................................................................................33
Troubleshooting chart.................................................................34
Drilling and Milling................................................................35-54
Wiring diagram...........................................................................55
