> Tektronix tek 492 492P 496 496P service manuals i &ii
Tektronix tek 492 492P 496 496P service manuals i &ii
Important...Please read the entire description...Important
Tektronix 492/492P or 496/496P Service Manuals I&II plus extras.
Click anywhere on this sentence to look at a schematic we took at random from one of the CD's.
Both CD's are of this quality. Right click to download, left click to open (You'll need Acrobat Reader). Zoom in and see the details. At a lesser resolution you will have problems seeing everything you need.
All schematics and block diagrams that required more than one scan are scaled and overlapped for easy construction of the original.
What we know about this particular product:
This manual has the schematics which were scanned at a higher resolution for good quality. Don't guess at what you're looking at, you can zoom to 400% without lose of clarity. Makes for nice clear diagrams.
On this CD we have the full Operators manual (492) and the booklet 'Fundamentals of spectrum analysis'. This a must for those new to this equipment. Even if you've been using one of these instruments for many years viewing many different signals you'll still learn from this one literature book on spectrum analysis. The operators and service manuals are written for those who already understand the fundamentals of viewing the spectrum of frequency domain.
Also on this CD you'll find the quick guide and Tektronix TekScope 12 no.1
Sales and Service C.E.T. Techs
Full Operators Manual (492) 77 pages
Fundamentals of spectrum analysis (22 pages)
TekScope Volume 12 no.1 (16 pages)
Acrobat Reader 8.0 (needed to view manuals)
