New port 450-a compact linear translation stage nrc 450A
Newport 450-A Compact Linear Translation Stage NRC 450A
* Load capacity: 10lbs (45N)
* Travel: rated 0.25" (6mm), measured 0.3" (7.7mm)
* Stage: 1" square, 4 threaded holes
* Thread: English (standard)
* Special features: Miniature
* Current retail price: $269.28
Newport says: "Model 450A Compact Ball Bearing Linear Stage incorporates ball bearing construction in a miniature package for applications where space is at a premium. The 1 in. (25.4 mm) square translating platform is supported within the frame by balls riding between opposing pairs of precision-ground, hardened rods. The stage is preloaded to remove wobble and play and is spring loaded against an 80-pitch lead screw for backlash-free travel. Multi-axis translation systems can be assembled by attaching the frame of one stage directly to the platform of another."
