Hydraulic pto gearbox for group 3 pump 1:3.5 ratio
Hydraulic PTO Gearbox For Group 3 Pump 1:3.5 Ratio
HYDRAULIC PTO GEARBOX FOR GROUP 3 PUMP
RATIO 1:3.5 WITH FEMALE SHAFT QUICK FITTING.
MAX CONT TORQUE OF THE PTO GEARBOX (Input side daNm) 46
MAXIMUM TORQUE OF THE PTO GEARBOX (Output side daNm) 13
FINAL OUTPUT SPEED OF PUMP/GEARBOX ASSEMBLY 1836 RPM
The Pto Gearboxes are designed for connecting gear pumps to farm tractor power take offs (PTO). Output speed of power take offs is 540 rpm which can be compared with the proper running speeds of hydraulic pumps. Different input running speeds can also be suitable, provided that the PTO gearbox output speed does not exceed 3000 rpm.
Made in shell-cast aluminum or in high mechanical resistance cast iron.
The gears have manufactured to ISO/DIN 3990-88 standards. Made in Steel UNI 18 PCR M03. Stub teeth guarantee very high resistance and run very quietly.
Made in steel UNI 16 CRN4. They are coupled with splined gears and are designed to stand the torque values stated in the catalogue.
The torque figures mentioned in the technical charts of all the PTO Gearboxes refer to continuous duty cycles. Torques under intermittent working conditions can be exceeded by 20%.
Please check the oil level via the special oil window every 50 hours. Working temperatures should not exceed 120 degrees celcius under continuos duty cycle.
Specifiy the correct pto gearbox
Please check with the Technical Sales Office if you are not sure which pto gearbox to use.
