Fci burndy patriot PATMD6-14V in-line hydraulic crimper
This is a FCI Burndy Patriot In-Line Hydraulic Crimping tool model PATMD6. Tool is in good physical condition and great operating condition. Has some scuffs and scratches from normal operating usage; no damage otherwise.
The crimper activates properly; press and hold the green button to begin the crimp; once it clicks, you press the black button to release and open the jaws. The jaw mechanism swivels up to 350 degrees as well. Crimping time is about 5 seconds and you can perform over 300 crimps on one charge.
These are normally used for crimping electrical connectors/splices.
Comes as pictured with (see more pictures below description):
* FCI Burndy PATMD6 In-Line Crimping Tool
* PATJAWSMD6-8 Jaw - "O" and "D3" Grooves
* Makita 1434 14.4v 2Ah NiMH Battery
* Patriot In-Line Series Brochure (PDF)
FCI Burndy PATMD6 Hydraulic Self Contained 6 Ton in-line crimper
The BURNDY IN-LINE tools are battery actuated and can be operated with one hand allowing for advance, retract and hold functions for easier operation. One hand operation allows the operator one free hand to position the connector and conductor while crimping.
The PATRIOT PATMD6-14V series of tools incorporate a high speed hydraulic pump generating 6 tons of crimping force. This design provides a consistent, reliable connection every time.
The IN-LINE tool features interchangeable MD6 series heads, capable of using W and X style dies in the permanent D3 groove. When ordering choose the tool that best suits your crimping needs. The IN-LINE tools feature 350 rotatable heads for operation in virtually any position.
Each PATRIOT IN-LINE tool uses standardBURNDY dies and off-the-shelf connectors available world-wide.
* Copper, Aluminum, ACSR. Steel, Copperweld, Alumoweld, 6201, 5005, Compressed, and Compact conductors
* Copper Taps: #10 solid - 2/0 stranded
* Aluminum and ACSR Taps: #14 solid - 4/0 ACSR. .
* True, one-handed operation for advance, retract, and hold.
* 6 ton output force for reliable compression connections.
* Pressure pop-off valve indicates completion of crimp
* Interchangeable scissor action crimp jaws allow easier access to tight spaces.
* Ram holds position when trigger is released to allow the operator to check alignment prior to crimping.
* Allows the use of standard Burndy W and X dies already in use.
* Large hand grip area allows easier operation with gloves
* Ergonomically balanced tool design helps lessen operator fatigue.
* Durable high impact formed carrying case.
* High capacity 2.6 AH batteries provide more crimps per charge.
* 14.4 volt Ni-MH battery eliminates voltage depression (memory issues).
