New acces usb-idio-8 i/o usb idio modules w/software ps
COMES WITH $79.00 OPTIONAL BOARD
USB-IDIO-8 - 8 isolated digital inputs and 8 isolated FET solid state outputs version
Internal plug in screw termination board $79
Whole sale value/cost approximately $300.00 +++
USB Isolated Input and Solid State Relay Output Digital I/O Modules
* 16 individually optically isolated inputs (channel to channel and channel to ground)
* Polarity insensitive AC/DC inputs accept up to 31 VDC or AC RMS
* Jumper selectable filtering per input channel for AC or voltage transients
* 16 optically isolated fully protected high-side FETs capable of switching up to 2A
* Internal removable screw terminal board for easy wiring
* All power drawn from USB port, no external power adapter required
* USB/104 form-factor for OEM embedded applications
* Small, (4 x 4 x 1.4 ) rugged industrial enclosure
* Custom high-speed function driver
* PC/104 module size and mounting compatibility
* Type B USB connector features industrial strength and high-retention design
* Input only and solid state output only versions
* Eight input/output version
* External power for high current capabilities
* Extended temperature and DIN rail mounting provisions
* OEM version (board only) features PC/104 module size and mounting compatibility
* RoHS available. Please contact us for ordering information
