Kwh energy meter electricity utility 120/240V 100A #3
KWH Energy Meter Electricity Utility 120/240v 100A #3
NEW!!-This is a revolutionary meter at an extraordinary price!!!
Optional**Watertight enclosures available
This is a brand new kWh meter design, manufactured for EKM Metering, the most advanced type electronic KWH meter available on the market, model EKM-25IDS, 3 wire, 100 amp version. These were made specifically for U.S. 3-wire 120/240 (range: 84-168/156-312) volt single phase (2 phase) metering. They require 156 to 312 volts for operation. Installation is easy, since the meter is completely self contained, no external current transformers (CT's) or other extras as with many other electronic type meters. However, installation should only be performed by a knowledgeable, qualified electrician. The 2 "hot" service wires are simply passed through tubes in the meter housing (3/8" diameter, Up to #2 AWG insulated wire), and 2 screws are tightened to pierce the wiring to power the meter-less than 1 watt required. Installation and instruction manual included. Dimensions are approx. 3"w x 4"h x 2.5"d.
The meters have a non-resetable, 5 digit LCD readout with hundredths, and read directly in kWh, no conversion factors as with some other electronic meters. They have a built-in PULSE OUTPUT, 800 pulses per kWh. They are perfect for remote and automatic meter reading (AMR) applications.
***Please Note-Some of the photos in this listing are for illustration purposes, and do not represent something included with the listed item. This listing is for the METER ONLY.
Also available in 120 volt version and in a "Smart" version-with RS-485 serial communication and on-board data storage.
If you need other types of kWh meters-
120 volt models, "Smart" meters with built-in data communication,
or external current transformer models,
