> Kulicke & soffa 4523A digital wedge wire bonder 4523-ad
Kulicke & soffa 4523A digital wedge wire bonder 4523-ad
KULICKE & SOFFA 4523A DIGITAL WEDGE WIRE BONDER 4523-AD
K & S Kulicke & Soffa 4500 Series Semi-Automatic Wedge Wire Bonder Station
K & S 4523A Digital Wedge Wire Bonder SemiAutomatic
Manufacture Date: Oct 2001
Voltage: 115V AC, 4-Amp, 50/60 Hz
With Leica S6 Stereo Microscope
With Pair of Leica 16 x /16 Microscope Eyepieces, Part No. 10446355
With Volpi Intralux 4000 Light Source Fiber Optic Illuminator with Light Guide Cables, Lamps, Power Cord, etc
Manufactures Unique Features & Sets
Independent Manual Z axis control, separate from X and Y axis control.
Independently adjustable Wire Parameters, up to 6 channels
- Separate Force control for each bond, adjustable and independent per channel.
- Separate Bond Time control for each bond.
- Separate Bond Power control for each bond.
Digital Programmable per-wire Bond Recipes
- Up to 200 Bond Recipe storage
- Non-volatile RAM; programs will not self-erase
- 6 independent Bond Channels; include all parameters
- Multi-Wire capable; up to 3-wire Program capability
- Programmable 2nd bond step, with automatic 2nd bond completion
Clamp Tear or Table Tear wire termination.
- Programmable choice of wire termination function
- Controls Tail length and Tail angle
Advantage for sensitive materials
Lange Coupler Mode is included
- Programmable, low loop formation
- Provides for extremely short wire lengths used in Microwave Products
No springs are used to apply bond force; digitally controlled components are utilized.
Standard bonding , Deep Access and Ribbon bonding with same Bond Head tool assembly .
- No need to change tool assembly"
Motorized Wire Clamp Motion with Linear Stepper Motor
Auto-Stepback Mode is included, with a motorized Y stage
- Operates in Auto 2nd bond mode
Automatically stitch up to 6 bonds
No vacuum or air pressure is required for operation.
Standard Reset Height is .260 with full range fine Z Motion control.
High Reset Height is .500 for tall package clearance.
Wire Sizes are from .0007 dia., to .003 dia. (18 75 Micron Diameter) Aluminum and Gold.
Ribbon Sizes are up to .001 x .010 (gold).
