Sunrise telecom CM500 ip cable modem network analyzer
* Sunrise Telecom CM500IP With Options:
Sunrise Telecom CM500 IP Cable Modem Network Analyzer
Automatically Test & Verify Analog, Digital Video or Cable Modem Installations
* Now with DOCSIS 1.1 and BPI+
The CM500 provides a comprehensive set of verification, testing and troubleshooting tools for the Installer and Service Technician responsible for analog, digital video and cable modem services... and now VoIP.
* Comprehensive cable modem, digital & analog tests
* "SMART" one-button tests with programmable pass/fail limits
* Cable Modem and PC Emulation
* Easy to interpret color bar graphs
* Automated or manual test data storage and upload via network
* Proven "Sunrise tough" with all the digital experience you need built right in!
The Install Profilers provide three test locations, each with its' own set of programmable tests and Pass/Fail limits. Once the tests are selected and the limits are programmed, via the PC-IP software program, the user may select Tap Check, Ground Block Check or Set-Top Check to initiate the automatic test routine. Cable Modem Check is available only on the CM500 IP.
Each "SMART" test provides a simple Pass/Fail display indicating the outcome. An overall Pass/Fail indication is displayed in the upper left corner of the display, with individual Pass/Fail analysis of the analog, digital and cable modem tests, depending on the model in use.
The Install Profiler can also display a summary of the test results for each of the "SMART" tests that it performs. If enabled, easy to interpret color bar graphs provide a summary of the measurements and the Pass/Fail Limits on an auto-ranging scale. Detail screens are provided for each active group of measurements (analog, digital and cable modem, coinciding with the model in use).
The Install Profiler's manual SLM mode includes a full complement of comprehensive analog and digital measurements. The manual SLM mode provides state-of-the-art Signal Level Meter measurement, data storage and result analysis, making it a true "One Meter Solution," ideal for installing and testing analog and digital drop networks.
Eliminate Ingress, Noise and CPD in the return. The return path is often the most challenging portion of the network. The Install Profiler offers the simplest semi-automated test method for testing and troubleshooting the return path. The Return Spectrum will measure "bursty" TDMA return signals, intermittent ingress, noise and CPD (common path distortion) at three programmed or user selectable frequencies. Simply set the markers and the Install Profiler does all the work, reading out the carrier level of TDMA signals, CPD or ingress, C/I ratio and C/N ratio.
Detail screens can be accessed to view bar graphs of the test results if the programmer has allowed access.
Ensures a Quality Installation
Programmable SMART tests can verify a few key channels or the entire channel plan. Tests can range from a few simple level measurements to a full complement of comprehensive tests suitable for FCC proof-of-performance certification. Quick and comprehensive testing will ensure safe operating margins, reduce call backs and solve problems other meters leave behind. All this while increasing the number of installations performed in a day.
