> New 650 ton hydraulic coining, forging, stamping press
New 650 ton hydraulic coining, forging, stamping press
NEW DCS/Goldpro -Precision Built in the USA
* HYDRAULICS: VARIABLE DISPLACEMENT, ELECTRONICALLY CONTROLLED PUMP
* CONTROLS: MICROPROCESSOR, CLOSED LOOP. ALL PROCESS
PARAMETERS ENTERED FRO TOUCH SCREEN
* SPEED: JOG- INFINITLY ADJUSTABLE
MANUAL- 2 SECOND CYCLE AT FULL TONNAGE AND
* COOLING: AIR TO OIL HEAT EXCHANGER
* METALLIC (AUTOMOTIVE STYLE) PISTON SEALS
* COAXIAL JACK PISTON FOR SMOOTH RAPID APPROACH
* LOW PRESSURE (4,800 PSI) HYDRAULIC SYSTEM USES COMMERCIAL HOSES, VALVES, ETC.
* MULTI HIT FEATURE ALLOWS UP TO 3 HITS PERCYCLE AT DIFFERENT TONNAGES AND DWELL TIMES
* PRESS CAN BE OPERATED CONTINUOUSLY AT MAXIMUM RATED TONNAGE
* OIL TIGHT ENCLOSURE KEEP ANY MINOR OIL LEAKS INSIDE THE MACHINE, NOT ON THE FLOOR
* WARRANTY: 1 YEAR COMPREHENSIVE, 2 YEAR FRAME AND PISTON SEALS
* TWO BUTTON, ANTI TIE DOWN ACTUATION.
* ELECTRICALLY INTERLOCKED 1/2" THICK POLYCARBONATE (LEXAN)FRONT SHIELD.
* 1/2" THICK POLYCARBONATE REAR SHIELD
* OIL OVER TEMPERATURE SHUT OFF
* RAM OVER TRAVEL PROTECTION
* Precision Built in the USA
* Strip Coining/Stamping Option $23,250.00 (See photo at top of page)
