Clippard modular 3-way multiple pilot valve minimatic
Clippard Modular 3-Way Multiple Pilot Valve Minimatic
Description: R-311 is a 3-way, spring return, fully ported valve with four pilots. Any one of the four pilots will actuate the valve. Actuating more than one pilot has no additional effect. Pilot signals must be absent at all four pilots to release the valve. The valve can be used normally - OPEN, normally - CLOSED, as a selector or as a diverter, all with four pilot inputs. It can also be used as a 2-way valve by plugging the exhaust ports. The R-311 may be used to replace an R-301 or R-321 valve in a circuit when additional pilot inputs are required. The R-311 also features an auxiliary pilot on the spring side of the valve. The auxiliary pilot will overcome any one or all of the four input pilots.
* Indicator shows valve in shaded position
* Multiple pilots reduces number of valves - reduces piping and space required
* Micro gap construction - snap action and no blow by
* Flow (SCFM @ 100 psig).......................9
* Pilot pressure (psig) minimum.............40
* Temperature........................32 to 180 F
* Working pressure.......................0 to 150
