South bend how to run a lathe manual 1906-1930S
This is a reproduction, not a photocopy, of an original South Bend How to Run a Lathe 24th Edition. This manual covers South Bend lathes made in the early years circa 1906-1930s. This is the operators manual that South Bend made for their 9"-24" lathes produced in that time frame. It covers everything shown in the contents section listed below and more.
For your continence, I have printed up three different version of this How to Run a Lathe manual to cover the large span of lathes that South Bend produced from 1906 to the late 1900s. The approximate date of the manuals I have are from 1906-1930s, 1930s-1950s, and 1950s-late 1900s. Some of the manuals overlap on certain machines and parts, because South Bend didn't change every machine and part at precise times, but I can help you match the appropriate manual with your machine.
Most of the lathes made for the time frame covered by this manual were made without gear boxes for threading, but some did have a gear box. Below is a picture of the gear box that was used in this time frame.
