Arduino standalone kit +MAX232 board+ extra parts
Arduino Standalone Kit + MAX232 to TTL Board
This could be the best value ARDUINO standalone kit in the Universe!!!
All components required to build a Standalone Arduino Serial Circuit.
Once you have an Atmega328 programmed with the arduino bootloader
you will need a way to upload your main programme, this is done by one
This kit comes complete with a ready built and tested RS232 to TTL converter (5V)
complete with two 4 pin female headers that will allow you to make a 'plug in lead'
This RS232 to TTL converter is a standard piece of kit found on any experimenters
workbench and can be used in many different projects.
Normally you would connect RX to TX and TX to RX when wiring to target board.
For more details on this converter please check my other listing for 'MAX232 to TTL'
Kit includes parts for 5volt power supply.
1-Atmega328P-PU already programmed with the Arduino bootloader.
1-40 way pin header (square pin)
1-USB socket (like in the Arduino Board)
What you get is a bag of parts, no instructions are provided but check out the links:-
http://lab.guilhermemartins.net/2009/05/06/paperduino-prints/
http://www.arduino.cc/playground/Learning/Standalone
http://www.arduino.cc/en/Main/Standalone
http://www.arduino.cc/playground/Learning/AtmegaStandalone
1-Use 100uf and 100nf caps on the input and ouput of the 5volt regulator
2-Connect 10k resistor from Rx pin2 of Atmega328 to ground.
3-Connect 100nf cap between pins 7 and 8 of Atmega328
3-Use 220R resistors with led's
4-On the led's short leg-ground, Long leg to +ve
This kit will allow you to build a standalone Arduino AND connect to your
computer to communicate with the Arduino IDE straight out of the packet!
Sent by First class Recorded Delivery in the UK - 1.40
