New innovair low flow duct smoke detector DH100ACDCLP
NEW INNOVAIR LOW FLOW DUCT SMOKE DETECTOR DH100ACDCLP
Brand NEW Original Packaging
With Accessories and Instruction and Manuals
Voltage: 120/ 240 / VAC, 24 VDC / VAC
Product Features & Specifications:
Conventional 4-Wire Photoelectronic Duct Smoke Detector with Low-Flow Technology
* Photoelectric, low-flow technology
* An air velocity rating from 100 feet per minute to 4,000 feet per minute (.5 meters per second to 20.32 meters per second)
* Patented interconnectability for multi-fan shutdown
* Two DPDT Form-C relay contacts
* 24 VAC/DC or 120/240 VAC
* Versatile mounting options
* A patented telescopic sampling tube
* A patented cover-tamper trouble signal
* Remote sounder/LED indicator options
System Sensor s Innovair DH100ACDCLP reduces the spread of smoke through HVAC air duct systems, including low-flow applications. As a photoelectric detector, it s ultra-responsive to the large smoke particles commonly found in duct systems. The DH100ACDCLP uses low-flow technology to sense smoke in the lowest air speeds, from 100 to 4,000 feet per minute. When smoke is detected, all interconnected units will initiate their relays. However, to quickly locate the fire source, only the detector sensing smoke will alarm. Two DPDT Form-C relay contacts, connected to auxiliary equipment, can also be configured to prevent the spread of smoke through a particular area.
