19.6" x 0.310" flat turntable belt - dual 502 1237 1245
This sale is for one flat turntable belt 19.6" X 0.310" X 0.027" (length X width X thickness). # 1407-537 equivalent. Scarce!!
Notice: Through a very fortunate purchase I have located this very scarce belt! These are all I have. Order what you need now or be disappointed later!
Click here to view all of my current Turntable Belt listings.
The above belt is a replacement for the belt used in the following models:
* Dual: 502, 1237, 1245. possibly others.
* There were many production changes and variations of the above models. This belt will fit most of them. However, before you order, make sure this is the correct belt size for your unit!
This is a name-brand replacement belt. All of my belts are brand-new, factory-fresh and not cheaper old stock. Quality is guaranteed!
* If the belt is old and stretched but not broken, flatten the belt with the two ends pinched together. Pull the belt very taute, but don't stretch it. Carefully and accurately measure the length of this doubled belt. Multiply this value by 2 to get the actual length (circumference) of the belt. Then subtract 5% to compensate for stretch. Then measure the actual width. Send these two dimensions, length and width, for each belt you need.
* If the belt is broken measure the length of the broken belt and subtract 5% from this length. This will give you the required length for a new belt. Measure the width, in inches. Send these two dimensions, length and width, for each belt you need.
* If the belt is missing or completely deteriorated then, using a string, measure the circumference of the path where the old belt traveled. Subtract 5% from this measurement. This will give you the required length for a new belt. Now measure the width of the space on the motor pulley where the belt sits, or the width of a piece of the old belt, if it still exists. Send the width and length for each belt you need and also let me know that these dimensions are for missing belts, and exactly how you took the measurements.
* If the belt is new and you simply want a spare replacement, send the actual dimensions of the belt without subtracting 5% for stretch.
****************************
