(3)elinco ac torque motor 40V 40HZ 600RPM 65OZ-in 2.7A
We lack a 40-volt power supply to test these motors with (as well as an appropriate capacitor) but we have checked them over with a multimeter and found them all to be in the same condition electrically. When tested for resistance, one lead-pair on each motor came out at 7.3 Ohms, and the other on each motor at 11.6 Ohms. When tested for voltage, each coil showed between .003 and .03 volts when the rotor was spun by hand.
Specifications according to motor label are as follows:
* Serial No: 801827 / 801869 / 793636
* Housing Diameter: 3-5/16 inch
* Housing Length: 4-5/8 inch
* Mount Pattern: 4-bolt, 90-degree, 2-1/16" dia.
* Shaft length (out from housing): 1-1/8 inch
* Shaft diameter: cant measure, obscured by wheel
* Wheel Diameter: 2-3/4 inch
