Fexac universal horizontal mill model up
FEXAC Universal Horizontal Mill Model UP
FEXAC Universal Horizontal Milling Machine
Table Size: 9-3/8" x 43-1/4"
Longitudinal Table Travel: 32-1/2"
Saddle Cross Travel: 9-1/2"
Knee, Vertical Adjustment: 17"
Table Swivel: +/- 45 Degrees
Max. Dist. Spdl. Center to Table Top: 17"
Dist From Spdl. Center to Underside of Overarm: 5-1/2"
Spindle Speeds (12): 48 - 1500 RPM
Long. & Cross Table Feed Rates: 7/16 - 20 IPM
Rapid Traverse Rate: 100 IPM
Spindle Nose Taper: #40 MTT
Overall Machine Dimensions: 64" x 58" x 66" High
3-Axis Automatic Power Feed
3 HP Spindle Motor Drive 230/460/3/60
Approximate Net Weight: 3,000 lbs.
