> New jet 14" x 40" 3 hp geared head engine lathe 321840
New jet 14" x 40" 3 hp geared head engine lathe 321840
JET GH-1440W-3, 14" X 40" 3 HP 3-Phase Geared Head Engine Lathe
Motor 3 HP, 230/460V Pre-wired 230V 3 Ph Spindle Bore 1-1/2" Spindle Mount D1-4 Number Of Spindle Speeds 12 Range Of Spindle Speeds 40 - 1,800 RPM Range Of Inch Threads 4 - 112 TPI Number Of Inch Threads 40 Distance Between Centers 40" Width Of Bed 10-1/2" Swing Over Bed 14" Swing Through Gap 20" Compound Slide Travel 3-1/2" Cross Slide Travel 6-3/8" Swing Over Cross Slide 8-1/2" Range Of Longitudinal Feeds .0012 - .0294 in./rev. Range Of Cross Feeds .0003 - .0103 in./rev. Number Of Longitudinal & Cross Feeds 40 Spindle Taper W/ Sleeve MT-5 (MT-3) Maximum Tool Size 5/8" x 5/8" Carriage Travel 37-1/2" Taper In Tailstock Spindle MT-3 Tailstock Spindle Travel 4-3/4" Steady Rest Capacity 3-3/4" Follow Rest Capacity 2-3/4" Overall Dimensions 73-3/4" x 29-1/2" x 47-1/2" (L x W x H) Net Weight 2,191 lbs.
* 14" x 40" 3 HP 3-Phase Geared Head Engine Lathe - 321840
