Honeywell RA889A1001 120V, 60 hz switching relay RA889A
120V, 60 Hz Switching Relay with Spdt switching
The RA889A Switching Relay with 24 V controller provides intermediate switching of line- and low-voltage devices from a line- or low-voltage controller and is typically applied in Hydronic heating systems.
High load switching capability.
Replaceable transformer fuse.
Long-life DC relay drive control technology.
Relay for use with external 24 Vac or 24 Vdc supply, with line-voltage control, or with internal 24 V transformer supply.
One model replaces many Honeywell models.
Secondary of transformer protected by replaceable 1A automotive fuse.
Enclosed switching relay with internal transformer, Spdt line voltage relay, plus Spst low voltage relay with Powerpile rating. 120V/60Hz 15 AFL/30 ALR ratings one line voltage contacts.
For switching of line- and low-voltage devices from a line- or low-voltage controller.
SPDT, plus PowerPile rated low voltage SPST relay
Thermostat Heat Anticipator Setting
24 Vac, 12 VA max., 9 VA available for external load. Secondary protected by replaceable 1A automotive fuse.
Honeywell electromechanical and electronic 2- or 3-wire
6 1/4 in. high x 4 7/16 in. wide x 3 1/2 in. deep
159 mm high x 118 mm wide x 89 mm deep
Operating Humidity Range (% RH)
Electrical Ratings (Primary Voltage)
Contacts Electrical Rating Contacts Max. Connected Load
Contacts Electrical Ratings (120 Vac AFL)
Contacts Electrical Ratings (120 Vac ALR)
Approvals, Canadian Underwriters Laboratories
Integral transformer, enclosure
Listed: File No. E4436, Guide No. XAPX
