High pressure hydraulic source air over & hand pump 20K
High Pressure Hydraulic Source Air Over & Hand Pump 20KPSI 15,383 Safety Set.
* dual powered high pressure hydraulic source (hand & air)
* large 20,000 psi main pressure gauge
* designed for safety-thick steel cabinet, external handles, gauge cover
* ~566 lbs, 30 by 28 by 39 inches raw
Condition looks good used, tested and operates well. Both hand pump and Air operated pumps. The hand pump handle is just a piece of pipe we stuck in as the original handle is AWOL.
We tested to about 7,000 psi with only 35 psi of air pressure input. The safety
rupture diaphragm is 15,383 psi. The main pressure gauge and high pressure
components look like they could easily handle the 20,000 psi. The entire apparatus
is enclosed in a heavy steel plate cabinet. The original hand pump handle is
missing-we stuck in a simple piece of pipe to operate it. There is some sort of
Note the really thick cover over the high pressure gauge. Consideration for safety should something break has been implemented through out the design of this unit.
The image above shows the compressed air input and pressure regulation parts.
The images below show the oil reservoir, hand pump (yellow) and air drive pump (bottom).
These images show the safety rupture disk apparatus which is set at just over 15,000 psi.
While the air driven pump looks like it would easily exceed 20,000 PSI (if it were not for the 15,000 psi rupture disk) we assume the hand pump is limited to 10,000 psi.)
This might be just what you need for your high pressure hydraulic source application.
