Nsk nakanishi high power air motor spindle amxf-5014BH
Nsk Nakanishi High Power Air Motor Spindle AMXF-5014BH
ULTRA PRECISION HIGH POWER AIR MOTOR SPINDLE AMXF-5014BH 1.97" (50mm) 12,400 min-1(rpm)
AMX-50 series has 3 speeds available 12,400 min-1(rpm)(27 cN m), 1/1 ratio, 4,500 min-1(rpm)(110 cN m), 1/3 ratio, and 1,500 min-1(rpm)(310 cN m), 1/9 ratio.
This short body, high torque motor/spindle uses a 115W air motor. The system is perfect for mounting on turret lathes, CNC gang tool lathes, special purpose machines and any other place you need high power and high torque in a small body.
Collet Nut (K-265) : Provided
AMXF-5014BH Air Motor Spindle Specifications
AMX-50 Series (1/1 Ratio) 12,400 min-1(rpm)
End Mill Capacity 0.039" (*1)
