Miyano bnd-20S cnc lathe, fanuc 0T, live tool, subspdl,
Miyano BND-20S CNC LATHE, Fanuc 0T, Live Tool, SubSpdl,
Miyano BND-20S CNC LATHE, Fanuc 0T, Live Tool, Subspindle, Chip Conveyor
One used Miyano BND-20S CNC Turning Center
To View a video of this machine under power copy and paste this link at
http:// /watch?v=ImpQC-GSvBA
Maximum Work Length: Bar/Chuck: 4"/4"
Main Spindle:Spindle Nose: Flat
Sub-Spindle:Spindle Nose: Flat
Main Turret:Tooling Stations: 8
Distance Between Flats: 8 1/4"
Slide Stroke (x/z axis): 4.05"/6.5"
Rapid Feed Rate (x/z axis): 472"/472"
Revolving Tool:Max. No of Unit on Turret: 4
Drive Motor (max. rating): 1.5HP
Dimensions (approx.): 96" x 62" x 68"
