Hp agilent 8494H attenuator *calibrated with warranty*
With Option 001 type N connectors
(we can provide the cable at an additional cost)
The Agilent 8494H dc to 18 GHz programmable step attenuator offers exceptional repeatability and reliability. 0 to 11 dB, 1 dB Steps. Precision gold-plated leaf springs ensure long life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option UK6. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Agilent 11716A/B/C interconnect kits provide quick connection of Agilent 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps. Features Frequency range: dc to 18 GHz Attenuation range: 0 to 110 dB, 10 dB steps Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz Maximum SWR: 1.5 to 8 GHz, 1.6 to 12.4 GHz, 1.9 to 18 GHz Repeatability life: 0.03 dB maximum, 5 million cycles per section Maximum RF input power: 1 W (average), 100 W (peak)
